| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 1-2176429-5 |
| Mount Type: | Radial Leaded |
| Size Code: | TO247 |
| Power Rating: | 100 W |
| Termination Type: | Tinned Copper Leads |
| Resistance: | 22 Ω |
| Rated Voltage: | 700 V |
| Dimensions: | 15.75 x 20.7 x 4.95 mm |
| Element Type: | Thick Film |
| Tolerance: | 5% |
| Number of Terminations: | 2 |
| Temperature Coefficient: | ±50 ppm/°C |
| SKU: | AMP1-2176429-5 |
1-2176429-5
| Heilind Number: | AMP1-2176429-5 |
| Manufacturer: | TE Connectivity |
| Manufacturer Number: | 1-2176429-5 |
| ECAD Model: | |
Specifications
Detailed Description
Enhance your circuitry with the MPT100 22R 5% Radial Leaded Resistor. With a power rating of 100W and a resistance of 22Ω, this component is designed for high-performance applications. The TO247 size code ensures easy integration, while the tinned copper leads provide reliable connectivity. Operating at a rated voltage of 700V, it offers robust protection against power surges. Its compact dimensions of 15.75 x 20.7 x 4.95 mm make it suitable for space-constrained environments. Featuring a thick film element and a tolerance of 5%, this resistor guarantees precise and stable resistance values. With a temperature coefficient of ±50 ppm/°C, it maintains its performance across a wide range of operating conditions. Upgrade your system with this RoHS-compliant resistor for superior quality and efficiency.
For Use With
| Product | Part # | Description | Stock |
|---|---|---|---|
 | TE Connectivity 4-2176429-7 |  |
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
