1394918-3

AMP1394918-3
Heilind Number:AMP1394918-3
Manufacturer:TE Connectivity
Manufacturer Number:1394918-3
Datasheet:Drawing
ECAD Model:
3D Model

Description:

DUOPLG5.0 BU-STE 3P

More >>

Specifications

AttributeValue
Product Category:
Board To Board PCB Connectors Card Edge Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1394918-3
Amperage:6 A
Housing Material:PA 6/6
Number of Rows:1
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Insulation Displacement Crimp (IDC)
Contact Material:CuNiSi
Pitch:.197 in, 5 mm
Voltage:250 V
Contact Type:Socket
Package Quantity:2618
Number of Positions:3
Housing Color:Gray
Mount Orientation:Right Angle
GPL:394
Profile:Standard
Packaging:Tray
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Circuit Application:Power
Contact Mating Area Plating:Tin
Contact Mating Area Plating Thickness:196.849 - 472.439 µin, 3 - 6 µm
Panel Mount:Without
PCB Retention:Without
PCB Contact Termination Area Plating:Tin
PCB Thickness (Recommended):.059 in, 1.5 mm
Connector Height:.287 in, 7.3 mm
Mating Alignment:Without
GPL Description:Appliances
Connector and Contact Terminate To:Printed Circuit Board
Product Code:G566
Wire Size:20 - 22 AWG, .35 - .5 mm²
Connector System:Wire to Board
ECCN:EAR99
Connector Contact Load Condition:Fully Loaded
Mating Retention:With
PCB Mount Alignment:With
Card Entry Location:Side
Accepts Wire Insulation Diameter:.087 in, 2.2 mm
Voltage Rating (UL):250 V AC
Housing Configuration:Both Ends Opened
Contact Retention:With
Compatible Wire / Cable Type:Discrete Wire
Contact Retention Type in Housing:Locking Lance
Insulation Displacement Slots:3
Connector and Housing Type:Receptacle
Material Flammability Standard:UL 94V-0
Part Aliases:1394918-3
SKU:AMP1394918-3

Detailed Description

Enhance power connectivity with the DUOPLG5.0 BU-STE 3P connector. Featuring a durable PA 6/6 housing in gray, this three-position socket is suitable for a variety of applications. With a 5mm pitch and IDC termination method, it offers easy and secure cable mount installation. Meeting UL 94V-0 flammability standards, it ensures safety in operation. The tin-plated contacts provide reliable conductivity, with a contact mating area plating thickness of 3-6 μm. Operating in a wide temperature range from -40 to 110°C, it guarantees performance in diverse environments. Ideal for appliances and other electronic devices, this RoHS-compliant connector is a dependable choice for your PCB assembly needs.
