| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 14310315401000 |
| Pitch: | 3.81 mm |
| Series: | har-flexicon® |
| Wire Size: | 30 - 14 AWG |
| Mount Angle: | Straight |
| Housing Color: | Green |
| Conductor Size: | 30 - 14 AWG |
| Current Rating: | 10 A |
| Voltage Rating: | 150 V |
| Contact Plating: | Tin |
| Number of Poles: | 3 |
| Contact Material: | Copper Alloy |
| Housing Material: | Nylon |
| Number of Levels: | 1 |
| Termination Method: | Screw |
| Flammability Rating: | UL 94V-0 |
| Insulation Material: | Nylon |
| Maximum Operating Temperature: | 110 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | HRT14310315401000 |
14310315401000
Specifications
Detailed Description
Introducing the har-flexicon® Vertical Connector, a versatile and reliable solution for PCB to cable connections. Featuring a durable Nylon housing in a sleek Green color, this connector is designed for easy screw termination, ensuring secure and stable contact. With a high current rating of 10A and 3 copper alloy contacts plated with tin, it guarantees efficient power transmission. Its 3.81mm pitch and straight mount angle offer flexibility in installation. Rated for temperatures ranging from -40°C to 110°C and meeting UL 94V-0 flammability standards, it ensures safety and performance in various environments. Suitable for wire sizes ranging from 30 to 14 AWG, it accommodates a wide range of applications. Trust in the har-flexicon® Connector for seamless connectivity in your projects.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
