14312414402000

HRT14312414402000
Heilind Number:HRT14312414402000
Manufacturer:HARTING
Manufacturer Number:14312414402000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

har-flexicon®, Connector; Connector, Horizontal; PA / PPA, Green; PCB to cable; Screw termination; Rated current: 10A; Contacts: 24

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:HARTING
Manufacturer Part Number:HARTING 14312414402000
Pitch:3.5 mm
Series:har-flexicon®
Wire Size:30 - 14 AWG
Mount Angle:Straight
Housing Color:Green
Conductor Size:30 - 14 AWG
Current Rating:10 A
Voltage Rating:150 V
Contact Plating:Tin
Number of Poles:24
Contact Material:Copper Alloy
Housing Material:Nylon
Number of Levels:1
Termination Method:Screw
Flammability Rating:UL 94V-0
Insulation Material:Nylon
Maximum Operating Temperature:110 °C
Minimum Operating Temperature:-40 °C
Part Aliases:
SKU:HRT14312414402000

Detailed Description

Introducing the har-flexicon® Connector, a versatile and reliable solution for your PCB to cable connections. This horizontal connector features a durable PA / PPA housing in a vibrant green color, ensuring both performance and visibility. With screw termination and a rated current of 10A, it offers secure and efficient power transmission. The 24 contacts, made of copper alloy with tin plating, guarantee high conductivity and corrosion resistance. Operating flawlessly in temperatures ranging from -40°C to 110°C, this connector is suitable for various environments. Its 3.5mm pitch and straight mount angle make installation easy, accommodating wire sizes from 30 to 14 AWG. UL 94V-0 rated for flammability, it meets stringent safety standards. Trust the har-flexicon® Connector for seamless connectivity in your applications.
