| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P5-621311 |
| Series: | P5 |
| Cap Color: | Red |
| IP Rating: | Symbol 3 |
| Case Color: | Silver |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .263 in |
| Contact Plating: | Silver |
| Switch Function: | Off-On |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Screw |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| Voltage Rating (AC): | 115 VAC |
| SKU: | OTTP5-621311 |
P5-621311
Specifications
Detailed Description
Meet the P5 Series Sealed Mil Grade Alternate Action Pushbutton Switch, SKU P5-621311. Designed for rugged applications, this switch features a durable aluminum housing and a thermoplastic actuator. With a red cap and silver case, it offers a sleek design. Operating in temperatures ranging from -40°C to 85°C, and boasting an IP Rating of 3, it ensures reliable performance in various environments. The SPST contact configuration, along with a 5A current rating at 28VDC, guarantees efficient power control. Its Off-On switch function, activated by a flat round button, offers easy usability. With a 25,000 cycle durability rating, this panel-mounted switch is built to last. Suitable for high reliability applications, it's a must-have in the aerospace, defense, and industrial sectors.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
