| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P5-A13124 |
| Series: | P5 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST |
| Actuator Type: | Button (Curved) |
| Case Color: | Black |
| Actuator Material: | Aluminum |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Silver |
| Actuator Length: | .13 in |
| Switch Function: | Off-On |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP5-A13124 |
P5-A13124
Specifications
Detailed Description
Introducing the Vandal Resistant, Sealed, Alternate Action Pushbutton Switch, part of our P5 series. Designed for durability with an aluminum housing and silver contact plating, this switch ensures reliable performance in harsh environments. Featuring a sleek black case with a silver button, it adds a touch of sophistication to any panel. The Off-On switch function and SPST contact configuration make it perfect for various applications. With a high IP6K8S rating, it guarantees protection against dust and water ingress. Operating at temperatures ranging from -40°C to 85°C, and with a voltage rating of 28VDC (115VAC), it offers versatility and safety. Ideal for industrial use, this button switch is the epitome of quality and functionality.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
