Enhance your electrical connections with our PIDG R 22-16 COMM 22-18 MIL 8 Ring Tongue terminals. Designed for optimal performance, these connectors accommodate wire sizes ranging from 22 to 16 AWG, ensuring secure and efficient crimping. With a closed barrel design and high-quality insulation, they offer reliable conductivity and protection against environmental factors. Operating at temperatures up to 105°C (221°F) and rated for 300V, these terminals are suitable for a wide range of applications. Compliant with RoHS standards, they are not only efficient but also environmentally friendly. Perfect for use in industrial and commercial settings, these terminals are a vital component in your electrical projects. Trust in the quality and reliability of our Rings & Spades line to meet your connectivity needs with precision.
AVAILABILITY
Immediate Shipment:NA
Stock Location:In Stock
Factory Stock:Call for Stock
Factory Lead:
Unit Of Measure:
Minimum/Multiple:1/1
Pricing
CALL:800.400.7041
Product Category:
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 320554
Series:PIDG
Connector Type:Ring Tongue
Voltage:300 V
Stud Size:#8, M4
Orientation:Straight
Operating Temperature Range:105 °C, 221 °F
Wire Size:22 - 16 AWG, .3 - 1.42 mm², 509 - 3260 CMA
Barrel Type:Closed
Insulated:Yes
Product:Rings & Spades
Terminal Angle:Straight
SKU:AMP320554
Plating Material:Copper / Tin
Weight per Piece:.805 g
Number of Holes:1
Wire Insulation Diameter (Max):3.18 mm / .125 in
Wire Insulation Diameter:2.03 - 3.18 mm / .08 - .125 in
Overall Length:20.24 mm / .797 in
Stud Diameter:4.17 mm / .164 in
Tongue Thickness:.79 mm / .031 in
Government Qualified:No
Wire Insulation Support:With
Heavy Duty:No
Wire/Cable Type:Regular Wire
Sealable:No
Shape Description:RING-041
Support Style:Non - Insulation Support
Part Alias:F92535-000,AMPS-0-0320554-0

Environmental Initiative Details

Environmental Initiative:RoHS
Compliant:Unknown
Date of this Information:Unknown
Notes:
