Enhance your electrical connections with this durable SPADE TERMINAL suitable for 18-14 AWG wires. Crafted from high-quality brass, it ensures reliable conductivity in various applications. The straight orientation and #8/M4 stud size make installation a breeze, while its open barrel design allows for easy wire insertion. With an operating temperature range of -40 to 110°C (-40 to 230°F), it's perfect for both indoor and outdoor use. RoHS compliant, this spade tongue terminal guarantees safety and quality. Upgrade your connectors with this essential component from our Rings & Spades collection.
Availability
Immediate Shipment: NA
Stock Location: In Stock
Factory Stock: Call for Stock
Factory Lead:
Unit Of Measure:
Minimum/Multiple: NA/NA
Pricing
CALL: 800.400.7041
Product Category:
Manufacturer: TE Connectivity
Manufacturer Part Number: 60774-1
Contact Material: Brass
Overall Length: 20.32 mm, .8 in
Stud Size: #8, M4
Orientation: Straight
Operating Temperature Range: -40 - 110 °C, -40 - 230 °F
Wire Size: 14 - 18 AWG, 1624 - 4106 CMA, .8 - 2.08 mm²
Barrel Type: Open
Insulated: No
Product: Rings & Spades
Product Type: Spade Tongue
Terminal Angle: Straight
SKU: AMP60774-1
Plating Material: Unplated
Underplating Material: None
Wire Insulation Diameter (Max): 3.556 mm / .14 in
Wire Insulation Diameter: 2.54 - 3.56 mm / .1 - .14 in
Stud Diameter: 4.17 mm / .164 in
Tongue Thickness: .46 mm / .018 in
Wire Insulation Diameter (Min): .1 in
Barrel Inside Diameter: 1.65 mm / 3.04 mm / .065 in / .12 in
Government Qualified: No
Wire Insulation Support: With
Heavy Duty: No
Wire/Cable Type: Regular Wire
Sealable: No
Shape Description: Square Spade
Support Style: Insulation Support

Environmental Initiative Details

Environmental Initiative: RoHS
Compliant: Unknown
Date of this Information: Unknown
Notes:
