42660-2
FASTON 250 RECEPTACLE 18-14 AWG TPBR
Enhance your electrical connections with the FASTON 250 Receptacle for 18-14 AWG wire terminals. Crafted from durable brass with a tin plating, this straight orientation receptacle ensures reliable conductivity. With an overall length of .753 inches, it accommodates tabs with a width of 6.35 mm and thickness of .81 mm. Suitable for a wide range of applications, it operates seamlessly in temperatures ranging from -40 to 110°C. Designed for F-Crimp installation, it accepts wire insulation diameters from .12 to .17 inches, making it a versatile solution for your crimp terminal needs. RoHS compliant, this receptacle guarantees both quality and environmental responsibility. Upgrade your connectors with this essential component from our Quick Disconnects collection.
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 42660-2 |
| Series: | FASTON 250 |
| Contact Material: | Brass |
| Contact Plating: | Tin |
| Overall Length: | 19.12 mm, .753 in |
| Material: | Brass |
| Compatible Tab Width: | .25 in, 6.35 mm |
| Compatible Tab Thickness: | .032 in, .81 mm |
| Terminal Type: | Receptacle |
| Orientation: | Straight |
| Operating Temperature Range: | -40 - 110 °C, -40 - 230 °F |
| Wire Size: | 14 - 18 AWG, .82 - 2.08 mm² |
| Crimp Type: | F-Crimp |
| Barrel Type: | Open |
| Accepts Wire Insulation Diameter: | .12 - .17 in, 3.1 - 4.3 mm |
| Product: | Quick Disconnects |
| Product Type: | Receptacle |
| SKU: | AMP42660-2 |
| Fully Insulated: | No |
| Connection Capacity: | Single |
| Receptacle Terminal Stock Thickness: | .41 mm / .016 in |
| UL Rating: | Listed |
| CSA Certified: | Yes |
| Mating Retention Type: | Dimple |
| Wire Insulation Support: | With |
| Wire/Cable Type: | Regular Wire |
| Insertion Force: | Low |
| Sealable: | No |
| Insulated: | No |
| Wire Stop: | No |
| Terminates To: | Wire & Cable |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 07/31/2021 | PCN-21-104079 - Tool Expansion. Capacity and Manufacturing Expansion in China along with TE Lickdale Plant (US) and TE Collegno (IT) to improve capacity and lead time. This expansion follows a strict procedure, which guarantees quality, ability to supply, and form-fit-function of the concerned products. The added manufacturing location operates a certified quality management system according to the standard industry requirements. TE internal release, based on our specifications, is executed before delivery to guarantee our products performance. Only applies to customers receiving products from TE Lickdale (US). | Product Change Notice Download |
